Overview

Dimensions: 160.6 × 51.7 × 28.7 mm (6.3 × 2 × 1.1") IR Night Vision: 6 m (20 ft) Smart Detections: ✓ People, Vehicles, Animals Resolution: FHD Field of View:

• Main Camera: H 138°, V 114°, D 155°

• Package Camera: H 97.5°, V 79.4°, D 118.2° Audio: Two-way audio Weatherproofing: IPX4 Mounting Options: Flat wall mount, 20° wedge (Included)

Performance

Networking Interface:

• WiFi 802.11a/b/g/n/ac

• Bluetooth 5.0

• GbE Support (UACC-Adapter-DBPOE) Video:

• Max Frame Rate: 30 FPS

• Main Camera: 2MP (1600 × 1200, 4:3)

• Package Camera: 2MP (1600 × 1200, 4:3) Optics:

• Sensor: Main 5MP CMOS, Package 8MP CMOS

• Lens: Fixed focal length

• Night Mode: IR LED illumination + IR cut filter

Hardware

Max Power Consumption: 10W Supported Voltage Range: 37—57V DC Power Method:

• 16–24V AC, 1.25A Max., 50/60 Hz

• USB-C: 5V DC, 2A Processor: Quad-core Arm® Cortex®-A53 Weight:

• Device: 253 g (8.9 oz)

• With Flat Mount: 286 g (10.1 oz)

• With Wedge Mount: 325 g (11.5 oz) Enclosure: Polycarbonate, Aluminum alloy Mount Material:

• Flat wall mount: Aluminum alloy

• 20° wedge: Polycarbonate Buttons: Ring + Factory-reset

Chime Compatibility

Mechanical:

• Broan-NuTone LA126WH, LA11WH, LA39WH

• Heath Zenith SL-2735

• Craftmade CTPW-RG

• Newhouse Hardware CHM3D

Digital:

• Broan-NuTone LA600WH

• IQ AMERICA DW-2850, DW-2840

Environment & Certification

Operating Temperature: -10 to 40° C (14 to 104° F) Humidity: 10 to 90% (noncondensing) Compliance: NDAA ✓ Certifications: CE, FCC, IC
