Mechanical

• Dimensions: 137 × 88 × 38.1 mm (5.4 × 3.5 × 1.5 in)

• Weight: 180 g (6.3 oz)

• Enclosure Material: Polycarbonate

• Mount Material: Polycarbonate, SGCC steel

• Available Colors: Black, White

• Indoor/Outdoor Use: Indoor only

Hardware

• Mechanical Life: 1,000,000 clicks

• Power Method: – UniFi Access Hubs – UL 294 Power-limited Class 2 PSU – UL 60950-1 / 62368-1 LPS / PS2 PSU

• Contact Type: (1) Normal Open

• Contact Rating: 30V DC, 2A

Compliance & Certifications

• UL 294 Level: – Destructive Attack: Level I – Line Security: Level I – Endurance: Level I – Standby Power: Level I

• UL 294 Statement: Compliance with IEEE 802.3 (at or af) specifications was not verified Designed to meet NEC Article 725.121 for Class 2 and 3 circuits

• CAN/ULC-60839-11-1 Grade: Grade 1

• Document Reference: UA-Button, V01

• Certifications: CE, UL 294, CAN/ULC-60839-11-1

• NDAA Compliant: ✓

Environmental

• Operating Temperature: 0 to 40°C (32 to 104°F)

• Storage Temperature: -40 to 70°C (-40 to 158°F)

• Operating Humidity: 5% to 90% noncondensing
