Mechanical

• Dimensions: 442 × 400 × 44 mm (17.4 × 15.7 × 1.7")

• Weight: – Without mounting brackets: 4.9 kg (10.8 lb) – With mounting brackets: 6.3 kg (13.9 lb)

• Enclosure Material: SGCC steel

• Mount Material: SGCC steel

• Supported Rack Depth: 400–600 mm (15.7–23.6")

• LCM Display: 1.3" Touchscreen

Performance

• Switching Capacity: 176 Gbps

• Total Non-Blocking Throughput: 88 Gbps

• Forwarding Rate: 131 Mpps

• Supported VLANs: 1,000

• MAC Address Table Size: 16,000

• L3 Table Size: – ARP Entries: 4,000 – IPv4 Routes: 1,000

• Packet Buffer Size: 4 MB

• Access Lists (IPv4): 128

• Access Lists (MAC): 128

Hardware

• PoE Ports: 40

• SFP+ Ports: 8

• Max. PoE Wattage per Port by PSE: 15.4W / 30W / 60W

• Max. Power Consumption: 600W

• Power Input Method: AC/DC, internal

• Supported Voltage Range: 100–240V AC

• Heat Dissipation: 2047.22 BTU/hr

Certifications & Compliance

• Certifications: CE, FCC, IC, Anatel

• NDAA Compliant: No

Environmental

• Ambient Operating Temperature: -5 to 45°C (23 to 113°F)

• Ambient Operating Humidity: 10 to 90% noncondensing

Software

• Application Requirements: UniFi Network Version 6.0.6 and later
